API Application Registration

1. Generate Authentication Token

· Go to System Admin --> Authentication Token --> Add one row

· User can choose the expiry date for the token.

· Check this Example

---

2. Create APIs in API Configuration screen

· Go to System Admin --> API Configuration --> Add rows

· For Import data, Table Name is required and should specify InsertType (Append,Replace,Clear All) also

· For Export data, SQL query is required.

· Check this Example

---

3. Call API to get access token using registration token

Use an API tool for test

· We use the API tool Postman to test Planvisage Web Application API

· For using Postman, follow the steps given below

Step 1: Install Postman API platform

· If you already installed Postman, skip this step

· Download Postman supported for your OS by clicking on the link: https://www.postman.com/downloads/

· Install Postman, Create a new free account and open it

Step 2: Create New Workspace and collection

· Create a Workspace (This is optional. If you want to create you should sign up first)

· Create a collection and name it. For Eg: TestAPI (Click on + icon near the Collections )

Step 3: Test Planvisage Web Application API

· Before testing API, check Planvisage Web Application API is live and running

· Click on Add a request

· Give request URL: http://localhost/WebApplicationSCM/JSONAPI/HealthCheck

Title : HealthCheck

Request type :  GET

Save it and send

If the Planvisage Web Application API is live and running then we will get the following response

Step 4: Call API to get access token using registration token

· Click on Add Request like in the image

· Give URL for AccessToken : http://localhost/WebApplicationSCM/JSONAPI/GetAccessToken

Type : POST

Title : GetAccessToken

    In Header part

Key : AuthenticationToken

Value : copy token from Authentication Token in System Admin and paste

Save it in the current collection and Send

· You will get an Access token like below

· Access token will be active for a few minutes.

So whenever you get the result "Access token Expired", come back to 'GetAccessToken' and click on Send again.

Copy the new access token and use it

---

4. Call API to Import or Export data using the access token

Step 1: Call API to Pull data using access token

· Here, Pull the data using gernerated access token with API defined for type Export.

· Click on Add Request like in the image

· Give URL for Pull Data : http://localhost/WebApplicationSCM/JSONAPI/PullData

Type : POST

Title  :  PullData

    In Header part

1st Key name :  AccessToken

Value : Copy the access token from the previous tab 'GetAccessToken' and paste

2nd Key Name : APIName

Value  :  Copy API name from table in which type is Export

Save it and Send

· You will get a result in JSON format

Step 2: Call API to Push data using access token

· Duplicate PullData by clicking on the three dots in PullData or 'Ctrl+D' or click on Add Request like in the image

· Give URL for Push Data : http://localhost/WebApplicationSCM/JSONAPI/PushData

Type : POST

Title  :  PushData

    Change in Header

2nd Key Name : APIName

Value : take name from table in which type is Import

For push data, the data should be in JSON format

Go back to PullData -> Copy one row of data from the result like in the image or copy the entire result

Return to PushData

Click on Body --> Click Row

Paste the code inside the Row; if you selected only one row of data, don't forget to close the brackets

Save it and Send

· You will get a successful result as given below

Hence the API Test is completed

The user can also test API for Replace/Clear All operation by configuring the Insert type in API Configuration screen or adding a new row
